Intel Core i7-7560U
2C / 4T 2.4 / 3.8 GHz 2017 laptop iGPU
The Intel Core i7-7560U is a Intel laptop processor from the Intel Core lineup, built on the Kaby Lake architecture and released in 2017. This CPU features 2 cores, a base clock of 2400 MHz, maximum turbo frequency of 3800 MHz and 4 MB of L3 cache. Manufactured using 14 nm process technology. The Intel Core i7-7560U is designed for the BGA1356 socket. It includes integrated Intel® Iris® Plus Graphics 640 graphics.
Specs
Type
Laptop
Cores
2
Threads
4
Speed
2.4 GHz
Turbo
3.8 GHz
Release Date
2017
GPU
Yes
Socket
BGA 1356
Current Price
Release Price
$415
L3
4 MB
Base TDP
15 W
Max TDP
Nm
14 nm
Unlocked
-
Official Site
| Type | Laptop |
| Cores | 2 |
| Threads | 4 |
| Speed | 2.4 GHz |
| Turbo | 3.8 GHz |
| Current Price | |
| Release Price | $415 |
| Release Date | 2017 |
| GPU | Intel® Iris® Plus Graphics 640 |
| Socket | BGA1356 |
| L3 | 4 MB |
| Base TDP | 15 W |
| Max TDP | |
| Nm | 14 nm |
| Unlocked | - |
| Official Site | intel.com |
| Performance Tier | Core i7 |
| Class | Intel Core |
| Code Name | Kaby Lake |
| Performance Cores | 2 |
| Efficiency Cores | - |
| Memory Type | DDR4 |
| Memory Channels | 2 |
| Max Memory | 32 MB |
| Bits | 64-bit |
| tjMax | 100°C |
| PCI Generation | 3 |
| PCI Lanes | 12 |
| L1 Cache | |
| L2 Cache | |
| Product IDs | Tray FH8067703037007 |
